Description：
1. Specification: CE and RoHS
2. Power:3W 6W 9W
3. LED Qty: 6pcs 12pcs 18pcs
4. Luminous Flux: 230LM 440LM 650LM
5. Color temperature: pure white/commercial white/warm white
6. Input voltage: DC12V
7. Base: G53
8. Housing: Aluminium alloy cooling fins
9. Product size:φ111mm*H82mm
10. Life span:50,000 hours
11.Replace 20W halogen light
Feature:
Unique design, beautiful appearance
Very light weight—0.144KG
Unique and perfect heat sink design, using fins shaped Aluminium
Uniform light output
External Power supply
Parameter:
| Part NO. |
LED Brand |
LED Quantity |
Power |
Lumen |
Beam Angle |
Work Voltage |
Work
Temperature |
Color |
| JJW-AR111W3 |
SMD3535 |
6 pcs |
3W |
210~240lm |
120° |
12VDC |
-40-50℃ |
WW/PW |
| JJW-AR111W6 |
SMD3535 |
12 pcs |
6W |
420~480lm |
120° |
12VDC |
-40-50℃ |
WW/PW |
| JJW-AR111W9 |
SMD3535 |
18 pcs |
9W |
630~720lm |
120° |
12VDC |
-40-50℃ |
WW/PW |
Dimension of JJW-AR111W3 JJW-AR111W6 JJW-AR111W9:
Connection:
Package:
Application:
To replace traditional bulbs, especially for museums, art galleries, restaurants, hotels, certain sales counters, bars, celebration places where UV or IR radiation is undesirable.
|
