Features:

1. supply voltage: 12v-24VDC
2. Loadable current: 6Ax2CH
3. Output channels: 2CH
4. output power: 144W/288W(12V/24V)
5. Control method: RF
6. Connection mode: common anode
7. Color cholse:  2(warm white and cold white)
8. Dimmering mothod: PWM
9. Grey steps: The power input polarity protection

Remote

Working voltage: 4.5VDC
Remote control way: RF
Launch frequency: 433Mhz
Controlable distance: more than 20 meters
Battery types: 3 pcs AAA type batteries
Standby power:  0.08mW
Power consumption: 6mW
Transmission power: 40mW
Key Number: 6 touch keys, 1touch wheel

Whole machine

Working temperature: -20℃―60℃
Identification: CE  ROHS
Weight: 380g
Packing size: L206.5*W136*H43mm
